| Technical data | Configure | |
| Parameter | Laser | Fibre laser |
| Wave length | 1064nm | |
| Average power | 50W | |
| If take optical coupler | Yes | |
| Repeat frequency of laser | 20kHz~80kHz | |
| Red light localization | yes | |
| Vibrating mirror parameters | maximum speed | 7000mm/s |
| resolution ratio | 0.001mm | |
| Repeat positioning accuracy | 0.0025mm | |
| optical output | Marking Area | 70×70mm,100*100mm(apolegamy) |
| Minimum line width | 0.01mm | |
| Min character | 0.2mm | |
| coolant passage | cooling-down method | air patenting |
| System Properties | Power Supply | 0.6KW/AC220V/50Hz |
| Environment Request | 0~35°C,Humidity≤90% | |
