| Item | Small Characters | High-speed printing | Micro Characters | Larger Small–size Characters | |
| UX-D160W | UX-D150W | UX-D140W | UX-D110W | ||
| Nozzle Size | 65µm | 55µm | 40µm | 100µm | |
| Maximum number of print lines | Up to 6 lines | Up to 4 lines | |||
| Maximum number of print characters | Up to 240 characters (Option: Up to
1,000 characters) |
Up to 1,000 characters | |||
|
Font (Horizontal x Vertical) |
4 x 5 | P | |||
| 5 x 5 | P | ||||
| 5 x 7(8),
9 x 7(8) |
P | ||||
| 7 x 10 | P | ||||
| 11 x 11 | P (Chinese only) | – | P (Chinese only) | – | |
| 10 x 12 | P | – | |||
| 12 x 16 | P | ||||
| 18 x 24 | P | P*2 | P | ||
| 24 x 32 | P | – | P | ||
| 30 x 40 | P | – | |||
| 36 x 48 | P | – | |||
| Character height | 2 – 10 mm | 2 – 8 mm | 1 – 5mm | 3 – 15 mm | |
| Display & input device | WYSIWYG design display: TFT LCD (10.4″ color), backlight provided input device: Touch panel, input sound provided | ||||
| Screen language
(2 languages selectable) |
English, Chinese, Korean, Thai, Vietnamese, German, French, Dutch, Italian, Spanish, Portuguese, Swedish, Danish, Greek, Russian, Czech, Polish, Arabic, Serbian, Turkish, Hungarian, Bulgarian, Catalan, Romanian, Finnish, Norwegian, Slovenian | ||||
| Maximum print rate (Character per second) (Font 5×5, space 1, 1 line) | Up to 1,148 (Option: Up to 2,563 *1) | Up to 3,173 | Up to 3,030 | Up to 468 | |
| Standard characters | Alphanumeric (A-Z, a-z, 0-9), symbols (27) and space: Total 90 | ||||
| User patterns | 200 patterns each for dot matrix (50 patterns for 30×40 and 36×48 fonts) | 200 patterns each for dot matrix | |||
| Print functions | Calendar, Count, Font mixture, Password | ||||
| Barcode printing | code39, ITF, NW-7, EAN-13, EAN-8, UPC-A, UPC-E, code128/EAN-128, GS-1 DataBar | ||||
| 2D printing | Data Matrix (Alphabet: 49 charac-
ters/Numerals: 98 characters), QR Code, Micro QR code |
Data Matrix (Alphabet: 49 characters/numerals: 98 characters), QR Code*2, Micro QR code | |||
| Message storage capacity | 300 Messages [Option: Up to 2,000 Messages (depends on data content)] | ||||
| Input signal | Print target detection, Printing stop, Rotary encoder pulse, Reciprocative printing,
Remote control (Run, Stop, High-voltage ON/OFF, Reset), (NPN/PNP Selectable) |
||||
| Output signal | Print in progress or Print complete, Online (NPN/PNP Selectable), Print ready, Fault, Warning (NPN Only) | ||||
| Data interface | RS-232C at baud rates selectable up to 115,200bps | ||||
| Ethernet (Modbus communication) | IEEE802.3, 100BASE-T | ||||
| External memory | USB for user data storage | ||||
| Printhead cable length / angle | 4m (in-line/90 degrees) | ||||
| Operating temperature range | 0-50°C (1067K Ink) | 0-40°C ((1067K Ink) | 0-35°C (1067K Ink) | ||
| Operating humidity range | 30-90% RH (no condensation) | ||||
| Power supply
(Automatic voltage selection) |
AC100-120/220-240V±10%
50/60Hz 120 VA |
||||
| Approval | CE, UL, cUL, C-Tick, FCC, ICES | ||||
| Dimensions (Width x Depth x Height) | 400 x 320 x 527 mm | ||||
| International protection | IP65 | ||||
| Approximate weight | 27kg | ||||
