Imaje 9018 Small character inkjet printer

Print features

▶ Mono-jet printhead

▶ G head (printing resolution: 71 dpi)

▶ Up to 3 lines of print

▶ Print speed: up to 3 m/s

▶ Font height from 5 to 24 dots

▶ Character height: from 1.8 to 8.7 mm

▶ Wide choice of characters (Latin, Arabic, Cyrillic, Greek, Japanese,

Chinese, Hebrew, Korean…)

options

▶ 4-line printing

▶ RS-232 connectivity

▶ Printhead pressurization kit (plant air required)

▶ Encoder and alarm connectivity

▶ 3m umbilical

Operations

▶ Message library (up to 100 messages)

▶ International operator/machine interface (choice of 31 languages)

▶ Large wysiwyg backlit blue screen

▶ Integrated online guidance for navigation and diagnostics

▶ Creation of logos directly on the operator/machine interface

▶ USB port

▶ M6’ ink circuit

▶ Jet Speed Control guarantees marking quality

▶ Automatic selection of fonts, depending on

print speed and printhead/object distance

▶ Possibility to choose different types of quick-drying black inks,

including MEK-free

▶ 2 sealed intelligent cartridges, 0.75 liter each

▶ Quick connect/disconnect of accessories (photocell, encoder, alarm)

accessories

▶ Printer supports: stands (stainless steel or aluminum),

table or wall mounting bracket

▶ Stainless steel printhead cover

▶ Photocell

▶ Encoder

▶ Alarm beacon (24 V)

Other characteristics

▶ Weight: 18.5 kg

▶ 2-meter flexible umbilical cable

▶ Stainless steel cabinet

▶ Dust/humidity protection rating: IP54 rating

▶ No plant air required

▶ Operating temperature range: 0° to 40° C, depending on ink used

▶ Humidity: 10% to 90% non-condensing

▶ Electrical power supply:100-120 V or 200-240 V with automatic

switching; frequency 50/60 Hz; power 34 VA
