| print head | Origin brand | Japan Ricoh (fully imported piezoelectric nozzle) |
| Spray print width | 54mm | |
| Injection accuracy | Longitudinal accuracy 600dpi Horizontal accuracy 200dpi-1200dpi for multiple adjustable | |
| Spitting spacing | < 2mm | |
| The printing speed | 0-150m /min | |
| Spithead life | 30B i llion actuations per nozzle | |
| Number of nozzles | 1280 (single nozzle) | |
| Industrial control computer | Case / display screen | 12 Inch capacitance screen |
| C PU | I ntel Core i5 7200U | |
| internal storage | The Kingston 8G supports a maximum memory of 32GB of dual-channel D DR3 1066 / 1333 | |
| caliche | 256G | |
| operating system | Original W in10 64 bit | |
| UPS | Uninterrupted Power Supply | Power off delay, UPS voltage stabilization function, power supply for about 25min. |
| Electrical parameters | air supply | Portable handle controls without manual adjustment of the cartridge switch |
| A C Input | 220V/50HZ | |
| Power of the whole machine | 1000W | |
| prepared Chinese ink | Ink type | U V Ink 1000ml / bottle |
| Ink brand | European and American imports | |
| Ink parameters | Level 7-8 filter accuracy 1-2NM particle accuracy <0.2UM | |
| environmental protection | Comply with the EU R oHS2.0 halogen | |
| Dust-free cloth | Material / Level | Ultra-fine anti-static dust-free cloth microfiber thousand level |
| Negative pressure system | Double way positive / negative pressure | Independent research and development, LCD screen display, convenient operation, continuous stability |
| accuracy | 0.1K pa | |
| Ink road system | Ink road | Full original ink road, unique design, stable operation, fine work, strong reliability |
| source | power supply system | Taiwan, China / Ming Wei |
| Sensor / Encoder | KTW /DFS60 | Yatai / internal secret control |
| weight | The weight of the machine | 40KG |
| service environment | service environment | Temperature 0-45 C Humidity 15% -75% |
