| Technical data | Configure |
| wavelength ( nm ) | 355 |
| repeat frequency | 10Hz to 150kHz ( up to 500kHz ) |
| Pulse width ( ns ) @30kHz | 18 |
| Average power ( W ) @30kHz | 5.0 |
| Average power stability | <±3% over 24 hours |
| Single pulse energy ( uJ) @30kHz | 100 |
| Single pulse stability | <3%rms |
| Spot pattern | TEM00(m^2<1.3) |
| Spot divergence angle | <2mrad |
| Spot diameter | 0.7mm |
| Spot roundness | >90% |
| Point to stability | <50urad |
| Polarization state | Horizontal |
| Polarization ratio | 100:1 |
| Use voltage | 15-30 |
| Refrigeration method | Water-cooling |
| Temperature range of the usage environment (°C ) | -10-50 |
